Measure
You share the openingSend the clear opening size, room temperature, what is stored and how goods move in. A drawing or a phone photo is enough to start.
Chiller Doors
Insulated doors for rooms held between 0°C and +10°C, built to your opening at our works in Hosur.
What the door does
A chiller door is opened dozens of times a shift. Each part below is a reason the room stays cold between openings.
-
A 60 or 80 mm polyurethane core keeps the warm loading bay out of the room, so the compressor runs less.
-
An EPDM gasket presses against the frame all round, stopping the leaks that cause frost on the evaporator and water on the floor.
-
Above 0°C the seal does not freeze, so a chiller door skips the heated frame a freezer door needs. That makes it lighter and less expensive to run.
-
Heavy-duty hinges or a sliding track carry crates, trolleys and pallet trucks without the leaf sagging off its seal.
-
Smooth PPGI or SS 304 skins take daily cleaning in food and dairy rooms, with no grooves where water and dirt can collect.
-
Every door is built to the measured opening, from a 750 mm staff door to a 3 m wide sliding door for forklifts.
Five ways to open a chiller
Pick how goods move through the door. Each type opens differently and fits a different opening.
-
Hinged single
For people and crates. The everyday chiller door for staff carrying crates and pushing small trolleys. Easy to use in small and medium rooms.
- Opening
- 750–1000 W × 2000–2400 H mm
- Best for
- Kitchens, dairy, pharma stores
-
Hinged double
For wide trolleys. Two leaves meet in the middle, so a trolley or roll cage can pass without one heavy leaf swinging into the aisle.
- Opening
- Made to size, wider than a single leaf
- Best for
- Produce rooms, central kitchens
-
Manual sliding
For pallet trucks. The leaf runs along the wall on a top track, so it needs no swing space in front. Suits pallet trucks and busy aisles.
- Opening
- 900–3000 W × 2100–3600 H mm
- Best for
- Cold stores, distribution centres
-
Motorised sliding
For forklifts. A motor opens and closes the door on a pull cord, push button or sensor, so it is open only as long as traffic needs.
- Opening
- 900–3000 W × 2100–3600 H mm
- Best for
- High-traffic docks, warehouses
-
Hatch
For passing goods. A small insulated opening for handing goods through or running a conveyor, without opening the whole room.
- Opening
- Made to size
- Best for
- Dispatch counters, conveyors
What goes inside your chiller?
Choose what you store and how it goes in. You get a starting door specification to send us.
0°C to +10°C
Typical holding range for fruit & vegetables
- Door
- Hinged single door
- Opening
- 750–1000 W × 2000–2400 H mm
- Leaf and skin
- 60 mm PUF, PPGI both sides
- Worth adding
- Kick plate at trolley height
A starting point, not a final specification. Our team confirms it against your room and drawings.
The specification
What a chiller door is built from, and the sizes we make it in.
The leaf
- Thickness
- 60 or 80 mm, 100 mm on request
- Insulation
- PUF or PIR, foamed in place
- Skins
- PPGI, PPGL, PCGI or stainless steel
- Seal
- EPDM gasket all round the leaf
Frame and fittings
- Frame
- Extruded aluminium, GI powder coated or stainless steel
- Operation
- Manual or motorised
- Options
- Vision glass, kick plate, push plate
Sizes and range
- Temperature
- 0°C to +10°C. Colder rooms: cold room doors
- Door types
- Hinged single or double, manual or motorised sliding, hatch
- Hinged
- 750–1000 W × 2000–2400 H mm
- Sliding
- 900–3000 W × 2100–3600 H mm
Rooms that run at chiller temperature
Each one has its own temperature range and its own cleaning routine, and the door is specified to match.
Food processing0°C to +4°C
Dairy+2°C to +4°C
Pharma cold chain+2°C to +8°C
Fruit & vegetables0°C to +10°C
Cold storage0°C to +8°C
Distribution centres0°C to +8°C
Hotels & kitchens+1°C to +5°C
From your drawing to a working door
Four steps, one team, from your first message to a door that closes on its seal.
Specify
We set the doorDoor type, leaf thickness, skin, frame, hardware and options are agreed with you and written into one approved specification.
Build
Made in HosurEach door is manufactured to the approved size at our Hosur works in Tamil Nadu, part of the Alfa PEB group, making since 1992.
Fit
Delivered and fittedWe coordinate delivery and give installation support, so the leaf sits square and closes onto its seal.
Our Clients
.webp)
.webp)
.webp)
.webp)
FAQs
Chiller door FAQs
A chiller room stays above 0°C, so the door needs a thinner leaf (usually 60 or 80 mm) and no heated frame. A freezer door runs below zero and needs a thicker leaf, a heater to stop the seal freezing shut, and often a pressure-relief port.
Hinged doors suit people, crates and small trolleys, and openings up to about one metre. Choose sliding when pallet trucks or forklifts go through, or when there is no room for a leaf to swing into the aisle.
60 mm PUF suits most chillers between +2°C and +10°C. Choose 80 mm for rooms near 0°C, for pharma stores, or where the door faces a hot, humid loading bay.
Ask us for a handle with an inside release, so the door always opens from inside the room even when it is locked from outside.
No. A strip curtain cuts the loss of cold air while the door is open, but only an insulated, sealed door holds the temperature overnight and when the room is closed.
The clear opening width and height, room temperature, what is stored, how goods move in, the number of doors and the site location.
Planning a chiller room?
Send us the opening size, the room temperature and what goes through the door. We'll recommend the right chiller door and share a price.
